#EagleFlex® Wirebraid Hoses: Fueling Hoses

Wirebraid Gasoline Pump Hose

Product Info

Resources

Specs / Construction

Features/Benefits

Recommended anywhere a hardwall or softwall hose is inappropriate.
Recommended for all gasoline and gasoline/Ethanol blends at Ethanol levels designated as “gasohol” (E10 maximum or less), diesel fuel and diesel fuel/biodiesel blends with nominal biodiesel concentrations up to 5% (B0-B5), kerosene and fuel oil (heating oil), leaded and unleaded gasoline.
Resistant to crushing and stands up to run-over.
Highly resistant to cuts, abrasions, sun and weather.
Flexibility of a softwall, durability of a hardwall.
Assures accurate readings at the pump.
Will not mark or scratch vehicle finishes.
Hose material is private branded and UL Listed to UL 330 and CAN/ULC-S612-99.
All curb pump hose assemblies are 100% pressure tested, inspected for electrical continuity and sample pull tested.

Construction

Tube: Black nitrile
Cover: Black CPE (chlorinated polyethylene), smooth finish
Reinforcement: Multiple textile braids with dual static wire helix
Temperature Range: -40°F to +180°F (-40°C to +82°C)

Couplings

Permanent internally expanded fixed chrome plated brass or external crimp zinc (L type).
Reattachable fixed and Reattachable swivel 3/4” and 1” male NPT. UL does not recognize field installation of reattachable fittings.

Order Info

Available Wirebraid Hoses

Hardwall Hoses

5/8” HOSES

Choose …

CP10WB08: 5/8” Wirebraid 8’ Assembly Hose

CP10WB09: 5/8” Wirebraid 9’’ Assembly Hose

CP10WB09.5: 5/8” Wirebraid 9.5’ Assembly Hose

CP10WB10: 5/8” Wirebraid 10’ Assembly Hose

CP10WB14: 5/8” Wirebraid 14’ Assembly Hose

3/4” HOSES

Choose …

CP12WB04: 3/4” Wirebraid 4’ Assembly Hose

CP12WB05: 3/4” Wirebraid 5’ Assembly Hose

CP12WB06: 3/4” Wirebraid 6’ Assembly Hose

CP10WB08: 3/4” Wirebraid 8’ Assembly Hose

CP10WB09: 3/4” Wirebraid 9’ Assembly Hose

CP12WB09SV: 3/4” Wirebraid 9’ Assembly Hose Swivel

CP12WB10: 3/4” Wirebraid 12’ Assembly Hose Swivel

CP12WB15SV: 3/4” Wirebraid 15’ Assembly Hose Swivel

CP12WB16: 3/4” Wirebraid 16’ Assembly Hose

CP12WB20: 3/4” Wirebraid 20’ Assembly Hose

1” HOSES

Choose …

CP16WB04: 1” Wirebraid 4’ Assembly Hose

CP16WB06: 1” Wirebraid 6’ Assembly Hose

CP16WB08: 1” Wirebraid 8’ Assembly Hose

CP16WB09: 1” Wirebraid 9’ Assembly Hose

CP16WB10X: 1” Wirebraid 10’ Assembly Hose

CP16WB100SV: 1” Wirebraid 100’ Assembly Hose Swivel

CP16WB100SVSV: 1” Wirebraid 100’ Assembly Hose w/ Swivel on both ends

CP16WB12: 1” Wirebraid 12’ Assembly Hose

CP16WB12SV: 1” Wirebraid 12’ Assembly Hose Swivel

CP16WB13: 1” Wirebraid 13’ Assembly Hose

CP16WB14: 1” Wirebraid 14’ Assembly Hose

CP16WB16: 1” Wirebraid 16’ Assembly Hose

CP16WB18: 1” Wirebraid 18’ Assembly Hose

CP16WB20: 1” Wirebraid 20’ Assembly Hose

CP16WB30: 1” Wirebraid 30’ Assembly Hose

EZ-Connects for this product have not been configured.
